The "Super Poison Snake" drone uses a jet engine and can reach speeds of over 300 kilometers per hour. It can fly for 25 minutes. It is equipped with radar and uses radio guidance in the first stage and infrared or television guidance in the second stage. It is specially designed to combat large cruise missiles in the air, such as the Shahid 136. This is a cheap air defense solution. It uses a catapult for takeoff and quick response. If the mission cannot be completed, it can use a retractable landing gear to land on the airport. It is reusable and cost-effective.
Length | 3253mm |
Wing span | 2790mm |
Turbine jet engine thrust | 18-26KG |
Center of gravity | From the leading edge of the wing to the wing 280mm |
Endurance | 25min |
Speed | 300KM/h |
Maximum takeoff weight | 45KG(with 15L fuel) |
Takeoff method | Launch tube/chassis |
Data Link | 30KM |
RTK antenna | Yes |
Route planning | Yes |
